Terlaris Fusion Splicer INNO Instrument VIEW5 PRO Original Nego

Fusion Splicer INNO Instrument VIEW5 PRO

INNO Instrument VIEW5 PRO Smart Core Alignment Fusion Splicer
Certainly! Here are the detailed features and specifications of the INNO Instrument VIEW5 PRO Smart Core Alignment Fusion Splicer:
Key Features:
High-Resolution Touch Screen:
• 5-inch color LCD touch screen with an intuitive GUI.
• Zoom in and out up to 520x magnification for clear and large fiber images.
Fast Splicing and Heating:
• Splicing time: approximately 7 seconds.
• Heating time: around 15 seconds.
Low Splice Loss:
Typical splice losses:
• 0.02dB for SM (Single Mode)
• 0.01dB for MM (Multi Mode)
• 0.03dB for DS (Dispersion Shifted)
• 0.03dB for NZDS (Non-Zero Dispersion Shifted)
• 0.02dB for G.657 fibers.
Built-in IoT Module:
• Real-time operation and management through the INNO View Pro Cloud Management System.
Enhanced Security:
• Full access control, anti-theft protection, and geolocation tracking.
Compact and Lightweight:
• Dimensions: 149 (W) x 177 (D) x 151 (H) mm.
• Weight: 2.21 kg.
Specifications:
Fiber Types: SM (G.652 & G.657) / MM (G.651) / DS (G.653) / NZDS (G.655) / CS (G.654) / EDF / BIF
Cladding Diameter: 80-150µm.
Coating Diameter: 100 – 3000µm.
Fiber Cleave Length: 5-16 mm.
Splice Mode: Max 128 modes.
Heating Mode: Max 32 modes.
Battery Capacity: Typical usage: 200 cycles / Power save usage: 250 cycles
Operating Conditions:
• Temperature: -10°C to 40°C.
• Humidity: 0-95% (non-condensing).
Storage Conditions:
• Temperature: -40°C to 80°C.
• Humidity: 0-95% (non-condensing).
This fusion splicer is designed for high precision and efficiency, making it suitable for various fiber optic applications, including FTTx, FTTH, core networks, and other precision-critical systems.

Mohon Tanyakan Stok Terlebih Dahulu Sebelum Order.

METODE PEMBAYARAN : Pembayaran dapat dilakukan dengan cara Cash On Delivery / Transfer Bank. * C.O.D. ( Cash On Delivery / Bayar ditempat) Khusus untuk wilayah Jakarta kami melayani pemesanan dengan cara pembayaran di tempat anda, Prosesnya : 1. Pesanan anda kami antar ke tempat anda 2. Setelah anda terima silahkan cek kelengkapan dan kualitas barang 3. Bila sudah ‘ OK’ dan tidak ada masalah baru dibayar Pembayaran ditempat bisa dalam bentuk tunai ataupun Transfer. Untuk Pemesanan dan Informasi Harga Terbaik, Hubungi : Rifki Faisal Bahri HP : 085353410506 / 089618877628 / 089531793777 Whatsapp : 085353410506 Email : rifkifaisal93@gmail.com / rifky.gps93@gmail.com Office : Cv.Mitra Laser Jl.Inpres 18 Komplek Sabar Ganda No 11 Tangerang selatan 15154
