VIEW5 PRO - INNO Instrument Fusion Splicer

Link Product: https://asiaindustri.com/product/inno-view5-pro-fusion-splicer/ or https://www.radionusantara.com/product/inno-instrument-view5-pro-fusion-splicer/

INNO Instrument VIEW5 PRO Smart Core Alignment Fusion Splicer

Certainly! Here are the detailed features and specifications of the INNO Instrument VIEW5 PRO Smart Core Alignment Fusion Splicer:

Key Features:

High-Resolution Touch Screen:

• 5-inch color LCD touch screen with an intuitive GUI.
• Zoom in and out up to 520x magnification for clear and large fiber images.

Fast Splicing and Heating:

• Splicing time: approximately 7 seconds.
• Heating time: around 15 seconds.

Low Splice Loss:

Typical splice losses:

• 02dB for SM (Single Mode)
• 01dB for MM (Multi Mode)
• 03dB for DS (Dispersion Shifted)
• 03dB for NZDS (Non-Zero Dispersion Shifted)
• 02dB for G.657 fibers.

Built-in IoT Module:

• Real-time operation and management through the INNO View Pro Cloud Management System.

Enhanced Security:

• Full access control, anti-theft protection, and geolocation tracking.

Compact and Lightweight:

• Dimensions: 149 (W) x 177 (D) x 151 (H) mm.
• Weight: 2.21 kg.

Specifications:

Fiber Types: SM (G.652 & G.657) / MM (G.651) / DS (G.653) / NZDS (G.655) / CS (G.654) / EDF / BIF

Cladding Diameter: 80-150µm.

Coating Diameter: 100 – 3000µm.

Fiber Cleave Length: 5-16 mm.

Splice Mode: Max 128 modes.

Heating Mode: Max 32 modes.

Battery Capacity: Typical usage: 200 cycles / Power save usage: 250 cycles

Operating Conditions:

• Temperature: -10°C to 40°C.
• Humidity: 0-95% (non-condensing).

Storage Conditions:

• Temperature: -40°C to 80°C.
• Humidity: 0-95% (non-condensing).

This fusion splicer is designed for high precision and efficiency, making it suitable for various fiber optic applications, including FTTx, FTTH, core networks, and other precision-critical systems.

Datasheet: https://asiaindustri.com/wp-content/uploads/2024/02/VIEW5-PRO-Catalog.pdf
