VIEW 8X - INNO Instrument Fusion Splicer

Link Product: https://asiaindustri.com/product/inno-instrument-view-8x-fusion-splicer/ or https://www.radionusantara.com/product/inno-instrument-view-8x-fusion-splicer/

INNO Instrument VIEW 8X Premium Core Alignment Fusion Splicer

The INNO Instrument VIEW 8X Premium Core Alignment Fusion Splicer is a top-tier device designed for precision and efficiency in fiber optic splicing. Here are its detailed features and specifications:

Key Features:

• AI-Driven Splicing: Utilizes artificial intelligence to enhance splicing accuracy and efficiency.
• IoT & GPS Integration: Equipped with IoT and GPS modules for real-time tracking and management.
• Fast Operation: Splicing time of 4 seconds and heating time of 9 seconds.
• High Precision: Ensures ultra-low splice loss for high-quality connections.
• User-Friendly Interface: Features a 5-inch high-resolution color LCD touch screen for easy operation.
• Durable Design: Built to withstand harsh environments, making it suitable for both field and lab use.
• Battery Life: Long-lasting battery that supports up to 355 splicing and heating cycles per charge.
• Storage Capacity: Can store up to 10,000 splice results.

Specifications:

• Splice Loss: SM: 0.01dB / MM: 0.01dB / DS: 0.03dB / NZDS: 0.03dB / G.657: 0.01dB
• Fiber Types: SM (ITU-T G.652 & G.657) / MM (ITU-T G.651) / DS (ITU-T G.653) / NZDS (ITU-T G.655) / CS (G.654) / EDF / BIF
• Fiber Count: Single fiber
• Fiber Diameter: Cladding diameter: 80 - 150µm, Coating diameter: 300µm – 3mm
• Splice Time: 4 seconds (SM FAST mode)
• Heating Time: 9 seconds (60 mm sleeve, FAST mode)
• Display: 5-inch color LCD touch screen
• Magnification: x360, x520
• Battery Capacity: 9000mAh
• Weight: 2.68kg (with battery)
• Dimensions: 162 (H) x 143 W) x 158 (D) mm

This fusion splicer is ideal for professionals who require reliable and efficient splicing in various environments.

Datasheet: https://asiaindustri.com/wp-content/uploads/2024/09/VIEW8X_Catalog.pdf
